LECA (Light Expanded Clay Aggregate) as a new environmental protection material is widely used in the construction field. It can be made of wallboard, brick and other new wallboard material. It also can be used for insulation, floor, lightweight concrete, water treatment and etc. Rotary kiln is the key equipment in the LECA production. The performance will effect the final LECA quality and production cost directly.

Model	Capacity （t/h）	Rotation Speed (rpm)	Support Quantity	Gear Box	Motor	Power (kw)
Model	Capacity （t/h）	Rotation Speed (rpm)	Support Quantity	Gear Box	Model	Power (kw)
Ø1.6×32m	0.8-1.5	0.58-2.85	3 Groups	ZQ75-50	YCTZ50-4A	18.5
Ø1.9×39m	1.6-4	0.53-1.59	3 Groups	ZQ125-7	YCT315-4A	37
Ø2.2×45m	2.5-8	0.214-1.64	3 Groups	Main ZS125-5 Auxiliary ZQ40-40	Main YCT315-4B AuxiliaryY112M-4	45 4
Ø2.5×50m	7.5-15	0.62-1.5	3 Groups	Main ZS165-5 Auxiliary ZS50-1	Main YCT355-4A Auxiliary Y160M-6	55 7.5
Ø2.8×55m	8.5-17	0.62-1.5	3 Groups	Main ZS165-6 Auxiliary ZS50-1	Main YCT355-4B Auxiliary Y160L-6	75 11
Ø3×60m	17-20	0.5-1.5	4 Groups	Main ZS165-3 Auxiliary ZS50-1	Main ZSN-280-11B Auxiliary Y160L-6	125 11
Ø3.2×50m	20-50	0.788-3.938	3 Groups	Main NZS995-28VBR Auxiliary ZL50-9-2	Main ZSN4-280-21B Auxiliary Y180L-6	160 15
Ø3.6×55m	30-92	0.39-3.9	3 Groups	Main ZSY500-40 Auxiliary ZSY180-31.5	Main ZSN-315-072 Auxiliary Y180L-4	250 22
Ø4.0×60m	32-105	0.39-3.9	3 Groups	Main ZSY630-35.5 Auxiliary ZL65-16	Main ZSN4-355-092 Auxiliary Y200L-4	315 30

1.Rotary Kiln can be divided into two parts: Drying Kiln and Burning Kiln.
2.The overall part is insert type layout. There is a connecting hopper in connection part. It is easy for maintenance.
3.It has the separated drive system. It is easy to control the separated rotation speed.
