APRON CONVEYOR







Technical Data


Model: BL650 -- BL1000

Apron width: 650 - 1000 (mm)



Chute height: 160 - 350 (mm)



Capacity: 20 - 200 (m³/h)

ADVANTAGE

1. Apron bucket made by wear-resistant steel plate with high precision, the cumulative error is small, running accurate, stable and reliable;



2. Adaptable, can transport material with bigger size & sharp edges & high temperature. In the transportation process the conveyor will complete material cooling and cleaning at the same time.



3. With chain transmission, apron conveyor has advantage of high intensity, high efficiency, reliable operation, heavy load, suite for long-distance transportation;



4. The chain has heavy load, high strength and high impact resistance because of heat treatment; chain plate joint sleeve use alloy steel carburizing with high abrasion resistance;



INTRODUCTION

Apron conveyor is driving by cycle running chain, that can transport all kinds of bulk materials along horizontal or inclined (inclination angle is less than 25 °) direction. Since the carrying part and running parts are made by metal, thus compared with other continuous conveying machinery, apron conveyor can transport material with bigger bulk density & size, and material with sharp edges with strong abrasion, especially suitable for conveying high temperature( 600~700 ℃ ) material. Therefore, apron conveyor is wildly used in mining, building materials, metallurgy, coal, chemical and other industries for transporting sharp, burning, corrosive material.

Application: Transporting high temperature material for cement, lime, clinker, mining industry.

SPECIFICATIONS

Model



Apron width

(mm)



Chute height

(mm)

Chute

Speed

(m/s)



Slope

(°)

Capacity

m³/h

Chain

Thickness

(mm)



Material

Pitch

(t/mm)

Destroy load

(KN)

Safety factor

Allowable traction(double chain)

(KN)

BL650

650

160~200

4

Q235

0.05~0.5

≤25

20~80

250

168

11.6

25

BL800

800

200~250

5

Q235

0.05~1

≤25

50~150

320

224

8

50

BL1000

1000

250~350

6

Q235

0.05~1

≤25

80~200

320

332

7.6

75





PROCESS

Apron conveyor is content head roller, apron and chain device, tail roller tension device, material protection device, frame and driving device.



If you are interested in our product design, specification, spare parts, quotation etc, please feel free to contact us by WhatsApp +8618037866379, or email us at zkeqpt@zkcorp.com.
