Belt conveyor is a main conveying equipment in mining machinery. Belt conveyor is stable delivery. Henan Zhengzhou Mining Machinery Co., Ltd is a professional belt conveyor manufacturer in China, and will introduce the features and selection of belt conveyor.

Features of belt conveyor

Belt conveyor is stable delivery and there is no relative movement between the material and the conveyor belt, to avoid damage to the material. Compared with other conveyor, the noise of belt conveyor is smaller, and it is suitable for relatively quiet occasions of working environment requirement. Belt conveyor can be made very long, within the transmission distance of 40M can be driven only with a power unit.

Selection points of belt conveyor

1 The frame can be made of carbon steel, stainless steel, and aluminum.

2 The belt can be selected according to the needs and the corresponding performance requirements of different materials, specifications of the belt.

3 The drive motor can be set below the rack or rack above according to the requirements of the user.

 4 The carbon steel body surface treatment can be selected according to the requirements of the user.

5 The speed adjustment requirements of the user can choose frequency control or variable speed gear motor.

6 The belt bandwidth is generally between 200mm - 1200mm (maximum transport object width × 120%). The workers standing operation flat is generally 850mm high (adjustable height).

7 the driving device is frequency control or electromagnetic speed, and conveyor belt type: PVC belt, rubber band and so on.

8 Chemical industries should generally choose the conveyor with skirts, ribs of the PVC or PU belt to meet the transportation volume, delivery speed and other requirements, meanwhile powder transport should consider the return collection.

9 The end of the belt conveyor can choose photoelectric control switch, and the product automatically stops in place to prevent the product falling.

10 When the user the inquiry and selection, please provide as much as possible, including details of the material name, size, material and machine material, approximate size, speed and delivery requirements.

If you still have any problems about the features and selection of belt conveyor, please contact us 0086-371-55902868.
