Ball grinding mill liner is the key component of ball grinding mill, and the installation way of ball grinding mill liner determines the running quality of ball grinding mill. This article will brief introduce the knowledge of ball grinding mill liner.

The knowledge of Ball grinding mill liner

The specifications of Ball grinding mill liner

The size of ball grinding mill liner has been basically uniform, the width of 314mm, the whole liner length is 500mm, half-liner length is 250mm, and the average thickness is about 50mm.

The arrangement of ball grinding mill liner

The arrangement of ball grinding mill liner should be staggered to each other to prevent the erosion effect of the grinding media wreckage and material on the cylinder wall.

The ball grinding mill liner is divided into whole liner and half liner. Fixed forms of ball grinding mill liner are consist of bolted connection and inlaid. A ball grinding mill, two positions with a bolt liner, the use of ball mill round head, square head and care round and so on. Installation, to make the liner close to the ball mill cylinder wall and no gap. In order to prevent the slurry or powder into the scouring ball mill cylinder, liner and ball mill between the cylinder liners. In order to prevent the outflow of slurry along the bolts, fixed ball mill liner with a cone with a washer. In the tapered surface of the packing ring, tighten the nut when the ring was tightly packed tapered washer to eliminate the ball mill bolt and cylinder bolt hole between the gap. In order to prevent the ball mill bolt loosening, bolts require a double nut or lock washer. Ball mill bolt connection fixed advantages: impact resistance, vibration resistance, more reliable.

Henan Zhengzhou Mining Machinery Co., Ltd. is engaged in the production of large and medium-sized series of ball grinding mill manufacturers, and is a professional ball grinding mill manufacturer setting research and development, manufacturing, sales of ball grinding mill. Welcome to visit and buy ball grinding mill liner and ball grinding mill. If you have questions about the ball grinding mill liner, please leave a message or contact us directly, and the phone number is 0086-371-55902868.
